Description: |
Usage : Graphite Electrodes has good electrical properties and chemical resistance, which has high mechanical strength at high temperature and good seismic performance.It is good conductor of heat and electricity, widely used in electric arc furnace steelmaking, refining furnace, ferroalloy production, industrial silicon, phosphorus corundum and other submerged arc furnace with an electric arc furnace smelting and other high temperature furnace. Features : high physical volume density super anti-press power low rate of electric resistance strong anti-oxidizes
Please contact us feel free to get more information.
Physical and Chemical Index of UHP
Items
Diameter: 700mm
Standard
Test data
Electrode
Nipple
Electrode
Nipple
Electrical resistance
μΩm
5.5-6.0
4.5
5.0-5.8
3.8
Flexure strength
Mpa
10.0
12.0
22.0
24.0
Modulus of elasticity
GPa
14.0
8.0
22.0
17.0
Ash content
%
0.2
0.2
0.2
0.2
Apparent density
g/cm3
1.66
1.69
1.78
1.80
Factor of expansion(100-600℃)
x10-6/℃
1.5
1.4
1.3
1.2
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
